Dell Poweredge T150 Server

Description rand Dell Model Name Dell EMC PowerEdge T150 Tower Server Processor One Intel Xeon E-2300 series processor with up to 8 cores or one Intel Pentium processor with up to 2 cores Memory • Four DDR4 DIMM slots, supports UDIMM 128 GB max, speeds up to 3200 MT/s, • Supports unregistered ECC DDR4 DIMMs only, NOTE: For Pentium processor, maximum memory speed supported is 2666 MT/s Storage controllers • Internal controllers (RAID): PERC H755, PERC H345, HBA355i, S150, • Internal Boot: USB, Boot Optimized Storage Subsystem (BOSS-S1): HWRAID 2 x M.2 SSDs, • External HBAs (non-RAID): HBA355e Drive bays 4 x 3.5-inch cabled SAS/SATA (HDD/SSDs) max 30.72 TB Power supplies • 300W Bronze 100-240 VAC, cabled • 400W Platinum 100-240 VAC, cabled (available only from Dec’21) Fans One cabled fan Dimensions • Height: 360 mm (14.17 inches), • Width: 175 mm (6.88 inches), • Depth: 453.75 mm (17.86 inches) with bezel, Form Factor 4U mini tower server Embedded management • iDRAC9, • iDRAC Direct, • iDRAC RESTful API with Redfish, • iDRAC Service Module Bezel Security bezel OpenManage Software •Open Manage Enterprise, • Open Manage Power Manager plugin, • Open Manage Support Assist plugin, • Open Manage Update Manager plugin Mobility Open Manage Mobile OpenManage Integrations • BMC True sight, • Microsoft System Center, • Red Hat Ansible Modules, • VMware vCenter and vRealize Operations Manager OpenManage Connections • IBM Tivoli Netcool/OMNIbus, • IBM Tivoli Network Manager IP Edition, • Micro Focus Operations Manager, • Nagios Core, • Nagios XI Security • Cryptographically signed firmware, • Secure Boot, • Secure Erase, • Silicon Root of Trust, • System Lockdown (requires iDRAC9 Enterprise or Datacenter), • TPM 1.2/2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ Embedded NIC 2 x 1 GbE LOM Front Ports • 1 x iDRAC Direct (Micro-AB USB) port, • 1 x USB 3.0 Rear Ports • 5 x USB 2.0, • 1 x iDRAC ethernet port, • 1 x USB 3.0, • 1 x Serial port, • 1 x VGA Internal Ports • 1 x USB 3.0 (optional) PCIe 4 PCIe slots: • 1×16 Gen4 (x16 connector) full height, half length, • 1×4 Gen4 (x8 connector) full height, half length, • 1×4 Gen3 (x8 connector) full height, half length, • 1×1 Gen3 (x1 connector) full height, half length Operating System and Hypervisors • Canonical Ubuntu Server LTS, • Citrix Hypervisor, • Microsoft Windows Server with Hyper-V, • Red Hat Enterprise Linux, • SUSE Linux Enterprise Server, • VMware ESXi (support only from Dec’21) OEM-ready version available From bezel to BIOS to packaging, your servers can look and feel as if they were designed and built by you
